SPECIFICATIONS:
Tension Testing Opening (Less Tooling): 38"
Compression Testing Opening (Less Tooling): 38"
Distance Between Columns/Screws: 16"
Table Size: 16" x 5.5"
Testing Stroke: 46"
Testing Speed (IPM): .00002 – 20
Crosshead Adjusting Speed (IPM): 20
Load Frame Dimensions: 35" x 23" x 58"
Electrical Requirements (V,Hz,PH): 200-230, 60, 1

EQUIPPED WITH:
• Computer with Keyboard & Mouse
• 24" LED-Backlit LCD Color Monitor or Better & Manual
• Microsoft Windows 10 Professional, Workstation
• MTGenius, Material Testing Software for Data Acquisition (Load, Position & 2 Strain),
Analysis and Computer Controlled Testing with Manual.
• MTGenius, Micro Console for Sensor Excitation and Analog/Digital Signal Processing with
USB Cable.
• Electronic Material Testing Control System in Custom Cabinet/Desk with PC Controls and
Crosshead Jog Controller.
• Precision AC Servo Motor and Drive
• 25kN Tension & Compression Load Cell
• Upper and Lower Quick Release Adaptors
