MI-8206 Econ Multi-Channel Vibration Controller

NEW MI-8206 Econ Multi-Channel Vibration Controller (16 to 32 Input Channels)

ECON MI-8206 MISO Vibration Controller is based on a high-speed bus architecture, paired with a real-time operating system. It
employs multi-DSP parallel processing technology and a distributed modular design, configurable with up to 32 input channels. enabling
remote access and control via gigabit networks. Combined with ECON's longstanding expertise in high-precision, low-noise, wide
dynamic range signal processing, it empowers you to build a real-time, high-accuracy, and powerful MISO vibration control system.
Supporting 14 major vibration control functions, the ECON MI-8206 MISO Vibration Controller delivers optimal solutions for diverse
environmental simulation testing needs across industries.

Features

• Compact and Rugged: The MI-8206 features 32 input channels in a single unit. Its rugged design makes it smaller and lighter
  than comparable products while offering superior vibration and shock resistance.
• High Precision: Dynamic range of no less than 120dB, 24-bit ADC and DAC, 32-bit floating-point DSP, and low-noise design
  techniques achieve 0.2% amplitude accuracy across a wide range and a bandwidth-dependent noise floor below 3μV at 20kHz.
• High Performance: Random control dynamic range exceeds 90dB, random control frequency reaches 18,750Hz, and random
  test analysis spectrum lines reach 25,600 lines.
• Powerful Capabilities: 14 major control functions with seamless data logging support for each test function, enabling effortless
  execution of diverse vibration tests.
• High Safety: Over 20 safety checks and interlock settings maximize protection for test personnel, test specimens, and vibration
  table equipment.
• Usability: Computers can be remotely controlled via Gigabit Ethernet. The PC software runs on the Windows operating system
  with a graphical interface, featuring customizable windows, cursor types, fonts, colors, and more.
• Supports various open-source Office software: Professional test reports can be automatically generated upon test
  completion, with data exportable to Excel format. Office software support extends beyond Microsoft Office and Microsoft 365 to
  include open-source alternatives such as WPS Office and OpenOffice.
• All-in-One Functionality: The vibration control interface features remote control capabilities for amplifiers. Utilizing vibration
  control software, it enables the activation/deactivation of ECON power amplifiers, gain adjustment, alarm message
  identification, and operational status monitoring. This allows you to simultaneously operate both the power amplifier and
  vibration controller from the control room.
